Cummins B190 33 SO11854E Parts Catalogue 1
| OPTION NUMBER | OPTION NAME | OPTION NUMBER | OPTION NAME |
| AF 9245ZZ | ADAPTER,FRONT DRIVE | C4938512 | HOSE,FLEXIBLE |
| C3925344 | SCREW,HEX FLANGE HEAD CA | C4988581 | NUT,HEXAGON FLANGE |
| C4931783 | FLANGE | C4991519 | NUT,REGULAR HEXAGON |
| AH 9021ZZ | HEATER，AIR INTAKE | FP91803ZZ | PUMP,FUEL INJECTION |
| C3922484 | CONNECTION,SPACER | C5260337 | PUMP,FUEL INJECTION |
| C3938158 | GASKET, CONNECTION | FS 9869ZZ | ACCESSORIES,FUEL SYSTEM |
| AP 9909ZZ | APPROVAL,AGENCY | C3976729 | ELBOW,MALE ADAPTER |
| C3415394 | SCREW,DRIVE | FS 9933ZZ | PUMP,FUEL TRANSFER |
| C5258272 | DATAPLATE | C3900631 | SCREW,HEX FLANGE HEAD |
| bp 9072zz | BLOCK,ENGINE | C3914284 | SPACER,MOUNTING |
| 3927772 | BEARING,CRANKSHAFT THRUS | C3916361 | SCREW,BANJO CONNECTOR |
| 3937214 | NOZZLE,PISTON COOLING | C3939258 | GASKET，COVER PLATE |
| C3008468 | PLUG,PIPE | C3963983 | WASHER,SEALING |
| C3900068 | DOWEL,RING | C4937767 | PUMP,FUEL TRANSFER |
| C3900257 | DOWEL, PIN | C4940671 | TUBE FUEL SUPPLY |
| C3900687 | PLUG,EXPANSION | FT 9161ZZ | PLUMBING,FUEL |
| C3900956 | PLUG,EXPANSION | C3903380 | SEAL,BANJO CONNECTOR |
| C3901306 | BUSHING | C3905307 | SCREW,BANJO CONNECTOR |
| C3902343 | DOWEL,RING | C3918188 | WASHER，SEALING |
| C3904483 | DOWEL, PIN | C3924726 | VALVE，CHECK |
| C3906619 | PLUG, PIPE | C4928975 | CLIP |
| C3906619 | PLUG, PIPE | C4929779 | TUBE,INJECTOR FUEL SUPPL |
| C3928797 | BLOCK,CYLINDER | C4931027 | MANIFOLD,FUEL |
| C3007635 | PLUG,EXPANSION | C4931029 | TUBE,INJECTOR FUEL SUPPL |
| C3900956 | PLUG,EXPANSION | C4931179 | BRACE,TUBE |
| C3900965 | PLUG,EXPANSION | C4991513 | SCREW,HEXAGON HEAD CAP |
| C3904217 | Screw,Hexagon Head Cap | FW90092ZZ | FLYWHEEL |
| C3913917 | CAP,MAIN BEARING | C3900269 | Washer,Plain |
| C3929016 | BEARING,MAIN | C3900269 | Washer,Plain |
| C3929021 | BEARING,CRANKSHAFT THRUS | C3977274 | SCREW,HEXAGON HEAD CAP |
| C3929027 | Gear, Crankshaft | C3977274 | SCREW,HEXAGON HEAD CAP |
| C3929037 | CRANKSHAFT,ENGINE | C4937926 | FLYWHEEL |
| BP 9091ZZ | COVER,FRONT GEAR | HD 9179ZZ | PUMP,AUXILIARY |
| A3918674ZZ | COVER,GEAR | C3967421 | ELBOW,MALE ADAPTER |
| C4991279 | COVER,GEAR | C4936138 | ELBOW，MALE ADAPTER |
| C4991305 | SEAL,OIL | HD 9186ZZ | PUMP,AUXILIARY |
| C3900629 | SCREW,HEX FLANGE HEAD | C4931172 | DISC，COUPLING |
| C3900629 | SCREW,HEX FLANGE HEAD | C4937729 | PUMP,HYDRAULIC |
| C3900633 | SCREW,HEX FLANGE HEAD | IC 9463ZZ | CONNECTION,AIR INTAKE |
| C3900633 | SCREW,HEX FLANGE HEAD | C3008468 | PLUG,PIPE |
| C3907998 | SCREW,ROUND HEAD CAP | C3918109 | SCREW |
| C3913995ZZ | HOUSING,TIMING PIN | C3920551 | COVER,INTAKE MANIFOLD |
| C3903924 | PIN,TIMING | C3938152 | GASKET,INT MANIFOLD COVE |
| C3904849 | RING,RETAINING | C4928946 | SCREW,HEX FLANGE HEAD CA |
| C3913994 | SEAL，O RING | IC 9494ZZ | CONNECTION,AIR TRANSFER |
| C3919683 | HOUSING,TIMING PIN | C3069053 | CLAMP,V BAND |
| C3915772 | SEAL，RECTANGLE | C3883284 | SEAL,O RING |
| C3918673 | GASKET,GEAR COVER | C4935790 | CONNECTION,AIR INTAKE |
| C3938156 | GASKET,GEAR HOUSING | IC 9495ZZ | CONNECTION,AIR INTAKE |
| C4931398 | HOUSING,GEAR | C3938158 | GASKET, CONNECTION |
| BP 9710ZZ | LEVER，ROCKER | C4938405 | CONNECTION,AIR INTAKE |
| C3284377 | ROD,PUSH | IC 9716ZZ | MOUNTING,INT CONNECTION |
| C3901221 | SCREW,HEXAGON HEAD CAP | C3919864 | SCREW，HEX FLANGE HEAD |
| C3920781 | Screw,hex flange head ca | LA 9007ZZ | BRACKET,LIFTING |
| C3934920 | Support,Rocker lever | C3908118 | BRACKET,LIFTING |
| BP 9711ZZ | FOLLOWER,CAM | C3910495 | SCREW,HEX FLANGE HEAD CA |
| C3931623 | TAPPET,VALVE | LB 9101ZZ | Labeling Engine |
| CC 9305ZZ | PLUMBING,CPR COOLANT | C3974406 | TAG,IDENTIFICATI |
| C3008468 | PLUG,PIPE | C3975443 | COVER,PROTECTIVE |
| C3910495 | SCREW,HEX FLANGE HEAD CA | C4983154 | TAG |
| C3910530 | Seal,Rectangular ring | C4983155 | DECAL |
| C3925226 | Connection,Water transfe | LC 9020ZZ | Cooler,Engine oil |
| C3960376 | CONNECTOR,MALE | C3900632 | SCREW,HEX FLANGE HEAD |
| C3960377 | ELBOW,MALE ADAPTER | C3906619 | PLUG, PIPE |
| C3978557 | TUBE,CPR WATER INLET | C3937743 | Cartridge,Lub oil filter |
| C3978558 | Tube,Cpr water outlet | C3942915 | Gasket,filter head |
| CL 9083ZZ | CLUTCH,REAR | C3957544 | CORE,COOLER |
| C3093867 | NUT,REGULAR HEXAGON | C4932124 | GASKET,OIL COOLER CORE |
| C3967108 | WASHER,SPRING | C4934217 | HEAD,LUB OIL FILTER |
| C4936133 | PLATE,CLUTCH PRESSURE | LG90316ZZ | GAUGE,OIL LEVEL |
| C4936134 | PLATE,CLUTCH PRESSURE | C3900955 | PLUG,EXPANSION |
| C4940327 | STUD | C3907712 | DIPSTICK |
| CM 9016ZZ | COVER, CAM FOLLOWER | C3968986 | TUBE,OIL GAUGE |
| C3284623 | GASKET,PUSH ROD COVER | LP 9064ZZ | PUMP,LUBRICATING OIL |
| C3900630 | Screw,Hex flange headcap | C3900677 | SCREW,HEXAGON HEAD CAP |
| C3918614 | HOSE,PLAIN | C4939587 | 上一个：CUMMINS B170 30 SO40468 PARTS CATALOGUE 2下一个：Cummins B190 33 SO11854E Parts Catalogue 2导航栏目新闻中心联系我们CONTACT US联系人：刘经理 手机：008613705041170 电话：008613705041170 邮箱：sales@primepowergenset.com 地址： 福建省福州市晋安区新店琴声商务广场 |
