DCEC Cummins Spare Parts

  • CUMMINS 6BTA5.9-C130 SO11535 PARTS CATALOGUE 2
CUMMINS 6BTA5.9-C130 SO11535 PARTS CATALOGUE 2

CUMMINS 6BTA5.9-C130 SO11535 PARTS CATALOGUE 2

  • Product description: CUMMINS 6BTA5.9-C130 SO11535 PARTS CATALOGUE 2
  • INQUIRY

CUMMINS 6BTA5.9-C130 SO11535 PARTS CATALOGUE 2

OPTION NUMBER OPTION NAME OPTION NUMBER OPTION NAME
3937214 NOZZLE,PISTON COOLING C3904531 RING,COMPRESSION PISTON
A3901258 GEAR,CRANKSHAFT C3918315 Ring,Compression Piston
A3901306 BUSHING C3920691 Ring,Retaining
C3008468 PLUG,PIPE C3932520 Ring,Oil Piston
C3900068 DOWEL,RING C3942581 Rod,Engine Connecting
C3900257 DOWEL, PIN C3900919 Screw,Connecting Rod
C3900687 PLUG,EXPANSION C4891178 Bushing
C3900956 PLUG,EXPANSION C3971970 BEARING,CONNECTING ROD
C3902343 DOWEL,RING A3920074ZZ INJECTOR
C3904483 DOWEL, PIN A3919339 INJECTOR
C3906619 PLUG, PIPE C3909356 Seal,Rectangular Ring
C3928797 BLOCK,CYLINDER C3971964ZZ CAMSHAFT
A3913917 CAP,MAIN BEARING A3907431 GEAR,CAMSHAFT
C3007635 PLUG,EXPANSION C3900227 SCREW,HEXGON HEAD CAP
C3900956 PLUG,EXPANSION C3927155 SUPPORT,CAMSHAFT THRUST
C3900965 PLUG,EXPANSION C3970366 CAMSHAFT
C3904217 Screw,Hexagon Head Cap C4928969 KEY,PLAIN WOODRUFF
C3929016 BEARING,MAIN PP97298ZZ MOUTING,CYLINDER HEAD
C3929021 BEARING,CRANKSHAFT THRUS C3283570 Gasket,cylinder head
C3929037 CRANKSHAFT,ENGINE PP98515ZZ TURBOCHARGER
BP 9710ZZ LEVER,ROCKER C3818823 STUD
C3284377 ROD,PUSH C3818824 NUT,HEXAGON FLANGE
C3920781 Screw,hex flange head ca C3901356 GASKET,TURBOCHARGER
C3934920 Support,Rocker lever C4035202 TURBOCHARGER
Q150B0875 SCREW,HEXAGON HEAD CAP PP98727ZZ Head,Cylinder
BP 9711ZZ FOLLOWER,CAM C3977600 HEAD,CYLINDER
C3931623 TAPPET,VALVE 3900250 COLLET,VALVE
BP 9807-01ZZ COVER,FRONT GEAR 3957912 SEAL,VALVE STEM
A3903663ZZ COVER,GEAR A3901117 VALVE,INTAKE
A3900709 SEAL,OIL A3901607 VALVE,EXHAUST
A3903794 COVER,GEAR C3008465 PLUG, PIPE
A3960319 GASKET,GEAR COVER C3008468 PLUG,PIPE
A3960338 HOUSING,GEAR C3008469 PLUG,PIPE
C3900629 SCREW,HEX FLANGE HEAD C3916691 SPRING,VALVE
C3900629 SCREW,HEX FLANGE HEAD C3920779 Screw,Hex flange head ca
C3900633 SCREW,HEX FLANGE HEAD C3920780 Screw,hex flange head ca
C3900633 SCREW,HEX FLANGE HEAD C3926700 SPRING,VALVE
C3903463 COVER,ACCESS HOLE C3957913 RETAINER,VALVE SPRING
C3903475 SEAL,RECTANGLE C3966452 HEAD,CYLINDER
C3907998 SCREW,ROUND HEAD CAP A3902606 PLUG,EXPANSION
C3913995ZZ HOUSING,TIMING PIN SCB-21ZZ KIT
C3903924 PIN,TIMING C3971993 Sensor,Temperature
C3904849 RING,RETAINING SM 9702ZZ MOUNTING,STARTING
C3913994 SEAL,O RING C3968470 SCREW,TWELVE POINT
C3919683 HOUSING,TIMING PIN SP 9031ZZ SPACER,FAN PILOT
C3915772 SEAL,RECTANGLE C3915490 PLATE,CLAMPING
C3938156 GASKET,GEAR HOUSING SS 9164ZZ PAINT
CM 9016ZZ COVER, CAM FOLLOWER C3991084 NAMEPLATE
A3900267 SEAL,GROMMET SS 9530ZZ KIT,ENGINE INSTALLATION
C3284623 GASKET,PUSH ROD COVER C3903380 SEAL,BANJO CONNECTOR
C3900630 Screw,Hex flange headcap C3906694 SEAL,RECTANGLE
C3918614 HOSE,PLAIN C3906695 SEAL,RECTANGLE
C3990730ZZ COVER,PUSH ROD C3910824 SEAL,O RING
C3907586 BAFFLE, BREATHER C3920773 WASHER,SEALING
C3990737 COVER,PUSH ROD C3930906 Gasket,Valve cover
C4928971 CLAMP,T BOLT C3936876 SEAL,RECTANGULAR RING
CM 9701ZZ COVER,CAM FOLLOWER C3937706 GASKET,OIL DRAIN
A3900267 SEAL,GROMMET C3939258 GASKET,COVER PLATE
C3900630 Screw,Hex flange headcap C3942915 Gasket,filter head
DA 9208ZZ DAMPER,VIBRATION C3963983 WASHER,SEALING
C3903857 SCREW,HEX FLANGE HEAD C4932124 GASKET,OIL COOLER CORE
C3958258 DAMPER,VIBRATION SS 9643ZZ KIT,ENGINE INSTALLATION
C4932908 FLANGE,CRANKSHAFT C4928803 CLAMP,SPRING HOSE
EA 9099ZZ ACCESSORIES,ELECTRICAL C4928804 GASKET,EXHOUT CONNECTION
C3901249 SCREW,HEX FLANGE HEAD C4928805 GASKET,EXHOUT CONNECTION
C4932506 WIRE,GROUND ST 9427ZZ MOTOR,STARTING
EC 9052ZZ THERMOSTAT C4935789 MOTOR,STARTING
1306R2-010-B2 THERMOSTAT TB 9766ZZ MOUNTING,TURBOCHARGER
EH97541ZZ MOUNTING,ALTERNATOR C3929881 GASKET,EXHAUST MANIFOLD
C3900631 SCREW,HEX FLANGE HEAD C3930249 SCREW,HEX FRANGE HEAD CA
C3900631 SCREW,HEX FLANGE HEAD TB 9792ZZ MANIFOLD EXHAUST
C3901249 SCREW,HEX FLANGE HEAD C3970066 MANIFOLD,EXHAUST
C3903105 SCREW,HEX FRANGE HEAD CA TH 9037ZZ HOUSING,THERMOSTAT
C3903210 NUT,HEXAGON FLANGE A3914409 HOUSING,THERMOSTAT
C3910923 SUPPORT,ALTERNATOR C3281246 Bracket,Lifting
C3910924 SUPPORT,ALTERNATOR C3900632 SCREW,HEX FLANGE HEAD
EH97543ZZ DRIVE,ALTERNATOR C3923331 Gasket,Thm housing cover
A3903095 SCREW,FLAT HEAD CAP C3926972 SCREW,HEX FLANGE HEAD
C3285958 BRACKET,BELT TENSIONER TO L003ZZ TOOL,SERVICE
C3288812 BELT,V RIBBED L00393 TOOL,SERVICE
C3900631 SCREW,HEX FLANGE HEAD L00402 BAG,SERVICE TOOL
C3937553 TENSIONER,BELT VC 9005ZZ Cover,Valve
